ROV
Dimensions383mm (l) x 331mm (w) x 143mm (h)
Weight3.9 kg
Thrusters6 Vectored Thrusters (Q-Motor)
Maneuverability6 Degrees of Freedom
Posture LockLock the ROV Pitch or Roll Angle with ± 0.1° Accuracy
HoveringKeep the ROV’s Suspended Elevation with ± 1 cm Accuracy
SpeedMax 3 Knots (1.5 m/s)
Depth Rating100m
Temperature Range-10 °C ~ 60 °C
Operating TimeMax 4 Hours
Battery Capacity9,000 mAh
Charging Time1h Quick Charge (70% Capacity)
Charging Voltage12.6V
CAMERA
Sensor1/2.3” SONY CMOS
Megapixels12MP
ISO Range100-6400 In Auto/Manual Mode
Field of View166° FOV
Shutter Speed5~1/5000 Seconds
AWB (Auto White Balance)2,500K ~ 8,000K
Exposure-3.0EV ~ 3.0EV
Photo Resolution4:3, 4000x3000
Photo FormatJPEG, DNG
Video Resolution4K UHD: 25/30 FPS | 1080P FHD: 25/30/50/60/100/120 FPS | 720P HD: 25/30/50/60/100/120/200/240 FPS
Video FormatMPEG-4 AVC/H.264, HEVC/H.265
StabilizationEIS (Electronic Image Stabilization)
Colour EncodingNTSC & PAL
Storage64GB Standard
LIGHTS
Brightness4000 Lumen LED Lights
CCT5,500K (Correlated Color Temperature)
Beam Angle120°
Brightness Levels3 Levels
CHARGERS
ROV Charger Input100-240V, 50/60Hz, 1.3A Max
ROV Charger Output12.9V = 6A
RC Charger Input100-240V, 50/60Hz, 0.5A Max
RC Charger Output5V = 3A
CONTROLLER
Wireless Features5Ghz Wi-Fi, 11a/n/ac
Battery LifeMax 4 Hours
SD Card SupportFormat in FAT32 or exFAT (Up to 64GB)
Q-INTERFACE
Ports–
Material–
Voltage9 ~ 12V
TETHER
Length100m Standard (200m/300m Optional)
Breaking Force100 kgf
Diameter4.0mm
Spool Dimensions238mm (l) x 213mm (w) x 205mm (h)
