ROV
Dimensions430mm(l) x 345mm(w) x 170mm(h)
Weight5.1 kg
Thrusters6 Vectored Thrusters (Q-Motor)
Maneuverability6 Degrees of Freedom
Posture LockLock the ROV Pitch or Roll Angle with ± 0.1° Accuracy
HoveringKeep the ROV’s Suspended Elevation with ± 1 cm Accuracy
Speed>3 Knots (>1.5 m/s)
Depth Rating100m-200m
Temperature Range-10 °C ~ 60 °C
Operating TimeMax 5 Hours
Battery Capacity69.12Wh*2
Charging Time1h Quick Charge (90% Capacity)
Charging Voltage100-240V
CAMERA
Sensor1/1.8" CMOS
Megapixels12MP
ISO Range100-6400 In Auto/Manual Mode
Field of View176° FOV
Shutter Speed5~1/5000 Seconds
AWB (Auto White Balance)2,500K ~ 8,000K
Exposure-3.0EV ~ 3.0EV
Photo Resolution3840 x 2160
Photo FormatJPEG, DNG
Video Resolution4K · 30fps/25fps | 1080p120/100fps 1080p60/50fps 1080p30/25fps | 720p180/150fps 720p120/100fps 720p90/75fps 720p60/50fps
Video FormatMPEG-4 AVC/H.264, HEVC/H.265
StabilizationEIS (Electronic Image Stabilization)
Colour EncodingNTSC & PAL
Storage128GB Standard
LIGHTS
Brightness10,000 Lumen LED Lights
CCT5500K (Correlated Color Temperature)
Beam Angle160°
Brightness Levels3 Levels
CHARGERS
ROV Charger Input100-240V, 50/60Hz, 3.0A Max
ROV Charger Output18V = 10A
RC Charger InputInput: 100-240 V, 50/60 Hz,0.5 A MAX
RC Charger Output5V = 3A
CONTROLLER
Wireless Features5Ghz Wi-Fi, 11a/n/ac
Battery LifeHot -swappable Power Supply
SD Card SupportFormat in FAT32 or exFAT (Up to 128GB)
Q-INTERFACE
Ports2 Accessory Ports (Upgrade-able to 6 Ports)
Material316 Stainless Steel
Voltage9 ~ 12V
TETHER
Length100m Standard
Breaking Force100 kgf
Diameter4.0mm
Spool Dimensions238mm (l) x 223mm (w) x 205mm (h)
